AIR COMPRESSOR 11-GALLON (41.6 L) - 058-8386-8AIR COMPRESSOR 11-GALLON (41.6 L) - 058-8386-8
TECHNICAL SPECIFICATIONS
PRODUCT NUMBER 058-8386-8
HORSEPOWER 3
TANK SIZE 11 U.S. GALLONS (41.6 L)
AIR DELIVERY (SCFM*) @ 40 PSI 6.2
AIR DELIVERY (SCFM*) @ 90 PSI 5.2
CUT-IN PRESSURE (PSI) 105
CUT-OUT PRESSURE (PSI) 135
PUMP DESIGN OIL-LESS
MOTOR INDUCTION
POWER 120 V, 60 Hz, 15 A
WEIGHT 66 lb 1 oz (30 kg)
POWER CORD SJT 14 AWG / 72" (1.83 m)
EXTENSION CORD SJT 12 AWG / MAXIMUM 30’ (9.1 m)
* SCFM: Standard Cubic Feet per Minute (= The volumetric flow rate of a gas
corrected to standardized conditions of temperature and pressure.)
This manual contains information that relates to PROTECTING
PERSONAL SAFETY and PREVENTING EQUIPMENT PROBLEMS. It
is very important to read this manual carefully and understand
it thoroughly before using the product. The symbols listed
below are used to indicate this information.
DANGER!
Potential hazard that will result in serious injury or loss of life.
WARNING! Potential hazard that could result in serious injury or loss of life.
CAUTION!
Potential hazard that may result in moderate injury or damage to equipment.
IMPORTANT! Installation, operation or maintenance information that is important but
not hazard related.
Safety Advice
DANGER!
1. RISK OF FIRE OR EXPLOSION. Do not spray a flammable or combustible liquid or
paint near sparks, flames, pilot lights or in a confined area. The spray area must be
well-ventilated. Keep compressor at least 20’ (6 m) away from spray area. Do not
carry and operate the compressor or any other electrical device near the spray area. Never smoke
when spraying. Use a minimum of 25’ (7.6 m) of hose to connect a spray gun to the compressor.
2.
RISK OF ELECTRIC SHOCK. Do not expose to rain. Store indoors. Hazardous voltage.
Disconnect from power source before servicing. Compressor must be grounded. Do
not use grounding adaptors.
3.
RISK OF BURSTING. Make sure the regulator is adjusted so that the compressor outlet
pressure is set lower than the maximum operating pressure of the spray gun or tool.
Before starting the compressor, pull the ring on the safety valve to make sure the valve
moves freely (see diagram on page 17). Drain water from tank after each use. Do not
weld or repair tank.
SAFETY GUIDELINES
