4
TECHNICAL SPECIFICATIONS
MOTOR SPECIFICATIONS
Horsepower 1/3
Voltage 115
Amps 4.1
Hertz 60 Hz
Phase Single
RPM 3450 RPM
Motor Type Permanent split capacitor (PSC)
Insulation Class A
Circuit Requirements 15 A (min) individual circuit
Duty Rating Continuous*
Shaft Seal Carbon/ceramic and stainless steel
Motor Shaft Stainless steel
Upper Motor Bearing Ball bearing
Lower Motor Bearing Ball bearing
Cooling Oil cooled
Motor Protection Auto reset thermal overload protector
*For continuous operation, the water depth must be at least 6” (15.24 cm) to prevent the motor
from overheating.
PUMP SPECIFICATIONS
Discharge Size 1 1/2” FNPT (3.8 cm)
Cord Length 10’ (3 m)
Cord Type SJTW, UL listed, 3-wire, 18 gauge
Pump Housing Cast iron
Pump Base Cast iron
Impeller Material Stainless steel
Impeller Type Non-clogging
Gasket Buna-N
Solids Handling 3/8” Spherical (9.5mm)
Liquid Temp. Range 32–120°F (0–49°C)
Operation Automatic or non-automatic
Fasteners Stainless steel
Max Flow Rate 2760 U.S. GPH (10,448 L/hr)
Maximum Head 25’ (8 m)
Max Pressure 10.8 PSI (74.5 kPa)
Weight 17 lb (7.71 kg)
model no. 062-3404-4 | contact us: 1-800-689-9928
