TECHNICAL SPECIFICATIONS
AUTOMATIC FLOAT SWITCH SPECIFICATIONS
Type Vertical with piggy-back plug
Switch on point* (factory set) 6” (15.24 cm)
Switch off point* (factory set) 2” (5.08 cm)
Material Polypropylene
Cord Length 10’ (3.05 m)
Cord Type SJOW, UL listed, 2-wire, 18 gauge
*Adjustable by changing tether length
DIMENSIONS
PERFORMANCE CHART
310 mm
12 3/16”
214 mm
8 3/8”
89 mm
3 1/2”
197 mm
7 3/4”
197 mm
7 3/4”
100 mm
3 7/8”
152 mm
6”
Lift 0’
(0 m)
5’
(1.5 m)
10’
(3 m)
15’
(4.6 m)
20’
(6 m)
25’
(7.6 m)
Flow 2760 U.S. GPH
(10,448 L/Hr)
2160 U.S. GPH
(8,176 L/Hr)
1800 U.S. GPH
(6,813 L/Hr)
1500 U.S. GPH
(5,678 L/Hr)
720 U.S. GPH
(2,725 L/Hr)
60 U.S. GPH
(227 L/Hr)
*Friction loss in piping not included in measurement
