MasterCraft 062-3422-0 User Manual

model no. 062-3422-0 | contact us 1-800-689-9928
4
TECHNICAL SPECIFICATIONS
For best performance, the maximum recommended hose length is 50' (15.2 m).
The pumping capacity or water flow rate of any pump depends on several factors.
The larger the inside diameter and the shorter the length of hose, the less
pressure that is lost (or the larger the flow rate). If the hose runs uphill or is
extra-long, use a larger diameter hose or rigid pipe.
062-3422-0
12 V / DC
1/10 HP
15 A
46' (14 m)
384 U.S. GPH (1454 L/h)
3/4" (1.9 cm)
11.8' (3.6 m)
TECHNICAL SPECIFICATIONS
0' (0 m)
10' (3 m) 20' (6.1 m) 30' (9.1 m) 40' (12.2 m) Max. Head
46' (14 m)
PERFORMANCE
Model Number
Voltage
Horsepower
Amps
Max. Head
Max. Flow
Discharge Size
Power Cord Length
384 GPH
(1454 L/h)
345 GPH
(1306 L/h)
296 GPH
(1120 L/h)
211 GPH
(799 L/h)
148 GPH
(560 L/h)

MasterCraft 062-3422-0 Specifications

General

Brand	MasterCraft
Model	062-3422-0
Category	Water Pump
Language	English
