model no. 062-3422-0 | contact us 1-800-689-9928
8
NOTICE: DO NOT coil or kink the hoses.
This equipment is only for use with an automotive, tractor or marine type
battery fully charged to 12 V DC. Battery current can cause severe burns and
start a fire if the battery is short circuited. Battery posts, terminals and related
accessories contain lead and lead compounds, chemicals known to cause
cancer and reproductive harm. Wash hands after handling.
Use insulated crimp type connectors.
6
5
Attach the pump (A) to a sturdy
base (table, board, etc.) to
prevent it from tipping over.
Make sure the hoses are as
straight as possible.
NOTICE:
Make sure the end of the outlet
hose is not under water. If the outlet is
under water, the pump may not work.
4
A
C
Thread a 5/8" (15.9 mm) or larger
garden hose (sold separately,
50'/15.2 m max. length) onto the
discharge outlet of the pump (A).
INSTALLATION INSTRUCTIONS
WARNING:
This pump CANNOT be submersed in water, and the motor CANNOT get wet at all. Getting the
motor wet could cause electrocution, which could lead to serious injury or death!
A
B
C
NO COILS
NO KINKS
Connect pump to power
source. Connect the red clamp
to the positive (+) type battery
terminal. Connect the black
clamp to the negative (-) type
battery terminal.
Power Supply: The pump is
designed for use with a 12 V
DC battery. Operation requires
a minimum 12 V power
supply.
