INSTALLATION PREPARATION
PREPARATION
Before beginning assembly of product, make sure all parts are present. If any part is
missing or damaged, do not attempt to assemble the product. Contact customer
service for replacement parts.
Estimated Assembly Time (new installation): 30 – 60 minutes
Tools Required for Assembly (not included): Wrench, Pliers, Cross-head Screwdriver,
Thread Tape, PVC Purple Primer, and PVC Cement
Accessories Required for Assembly (not included):
DETERMINING THE DEPTH OF WELL
Using a weight tied to as string, determine the depth of the well by dropping
the weight down the well, and then:
• Measure the ground level mark to where the string is wet. This is your
well's water level.
• This number must be 10' (3 m) under the pump's normal pumping level.
• Subtract 5' (1.5 m) from this measured water level number. This number
must be less than 25' (7.6 m).
• See Step 3 of Installation Instructions for a diagram.
INSTALLATION PREPARATION
Pressure Tank
1 1/4" (3.2 cm) and 1" (2.5 cm) PVC Adaptors
1 1/4" (3.2 cm) and 1" (2.5 cm) PVC Pipes
1" (2.5 cm) Discharge Tee
Tank Tee
Drain Valve
1 1/4" (3.2 cm) Foot Valve
1" (2.5 cm) MNPT x 1 1/4" (3.2 cm) SLIP PVC Adaptor
1 1/4" (3.2 cm) Single Drop Well Seal
Pressure Gauge
Relief Valve
1/4" (6.4 mm) Plug
