Specifications / Safety 2
For parts or assistance, call customer service at 1-877-455-5508
Limited Warranty
Mastercraft warrants that the products specified in this warranty are free from defects in material or
workmanship.
If within two (2) years from the date of the original consumer purchase, this pump shall prove to be defec-
tive, it shall be repaired or replaced subject to the terms and conditions set forth below.
General Terms and Conditions
This warranty shall not apply to acts of God, nor shall it apply to products which have been subject to neg-
ligence, abuse, accident, misapplication, tampering, alteration; nor due to improper installation, operation,
maintenance or storage; nor to other than normal application, use or service, including but not limited to,
operational failures caused by corrosion, rust or other foreign materials in the system, or operation at pres-
sures in excess of recommended maximums as set forth in the owner’s manual.
Requests for service under this warranty shall be made by returning the product to the retail outlet as soon
as possible after the discovery of any defect. We will subsequently take corrective action as promptly as rea-
sonably possible.
This warranty sets forth our sole obligation and the purchaser’s exclusive remedy for defective products.
DESCRIPTION
This Submersible Sump Pump is designed for home sumps.
Unit is equipped with a 3-prong grounding-type power
cord. Shaded-pole motor is filled with oil and sealed for
cooler running. Sleeve bearings on motor shaft never need
lubrication. Automatic reset thermal protection.
SPECIFICATIONS
Power supply required ................................115 V, 60 Hz
Motor duty....................................................continuous*
Liquid Temp. Range ....................32 to 77° F (0 to 25° C)
Individual Branch Circuit Required (min.) ................15 A
Discharge: ............................1 1/4" FNPT / 1 1/2" MNPT
*NOTICE: For continuous operation, water depth must be
at least 5" (13 cm), to prevent motor from overheating.
NOTICE: This unit is not designed for applications
involving salt water or brine! Use with salt water or
brine will void warranty.
PERFORMANCE
ELECTRICAL & SWITCH
SPECIFICATIONS
GENERAL SAFETY INFORMATION
Electrically powered sump pumps normally give many
years of trouble-free service when correctly installed, main-
tained, and used. However, unusual circumstances (inter-
ruption of power to the pump, dirt/debris in the sump,
flooding that exceeds the pump’s capacity, electrical or
mechanical failure in the pump, etc.) may prevent your
pump from functioning normally. To prevent possible water
damage due to flooding, consult your retailer about a sec-
ondary AC sump pump, a DC backup sump pump, and/or
a high water alarm. See the “Troubleshooting Chart” in this
manual for information about common sump pump prob-
lems and remedies. For more information, call customer
service at 1-877-455-5508.
1. Know the pump application, limitations, and poten-
tial hazards.
2. Disconnect power before servicing.
3. Release all pressure within system before servicing
any component.
4. Drain all water from system before servicing.
5. Secure discharge line before starting pump. An unse-
cured discharge line will whip, possibly causing per-
sonal injury and/or property damage.
GPH (LPH) AT TOTAL FEET (M)
Motor 5 10 15
Series HP (1.5 m) (3 m) (4.5 m)
CAPACITY GALLONS(L)/HOUR
62-3522-2 1/4
2280 1620 660 18’
(8,631) (6,132) (2,498) (5.5 m)
62-3518-4 1/3
2760 2160 1410 20’
(10,448) (8,176) (5,337) (6.1 m)
No flow
at height
shown
below
Motor Individual Switch Setting
Motor Full Load Branch Circuit in inches (mm)
Series HP Amps Req. (Amps)
On Off
62-3522-2 1/4 8.5 15 11
3
⁄4" (298) 4
1
⁄2" (114)
62-3518-4 1/3 9.0 15 13" (330) 6" (152)
