MasterCraft Air-Powered Gravity-Feed

IMPORTANT INFORMATION
12
AIR-POWERED GRAVITY-FEED SPRAY GUN KIT 058-9311-0
General use
This Mastercraft
®
Air-powered Gravity-feed Spray Gun is an HVLP or high-volume low-pressure
sprayer. This tool applies paint with less force, reducing the bounce of the material from the surface
to be painted. It features a stainless steel needle and nozzle to accommodate a variety of coatings.
The spray gun is capable of forming very large patterns.
Compatible compressors and air tool
GUIDELINES FOR PROPER USE AND OPERATION
Be sure to use the proper air compressor with Mastercraft
®
air-powered tools. The compressor
should be able to supply a minimal air delivery of 5.1 SCFM @ 40psi to ensure the compressor can
run continuously with the Mastercraft
®
Air-powered Gravity-feed Spray Gun. Using tools or
combinations of tools that together or separately require more than the air compressor can deliver
will reduce performance and could void the compressor or tool guarantee/warranty.
Air Compressor
Size & Power -
Large spray gun
1 1/2–2 HP 2 1/2 HP 3 HP and more
5–6 Gallons
Light-duty and
intermittent use
Light-duty and
intermittent use
Medium-duty and
intermittent use
8–11 Gallons
Light-duty and
intermittent use
Medium-duty and
intermittent use
Heavy-duty and
continuous use
15 Gallons
and more
Medium-duty and
intermittent use
Heavy-duty and
continuous use
Heavy-duty and
continuous use
Air Compressor
Size & Power -
Small spray gun
1 1/3–1 1/2 HP 2–2 1/2 HP 3 HP and more
4–6 Gallons
Light-duty and
intermittent use
Light-duty and
intermittent use
Medium-duty and
intermittent use
8–11 Gallons
Light-duty and
intermittent use
Medium-duty and
intermittent use
Heavy-duty and
continuous use
15 Gallons
and more
Medium-duty and
intermittent use
Heavy-duty and
continuous use
Heavy-duty and
continuous use
