PARTS LIST
29
AIR-POWERED GRAVITY-FEED SPRAY GUN KIT WITH ACCESSORIES 058-9311-0
Parts list - Touch- up Spray Gun
If any parts are missing or damaged, if you have any questions, please call 1-800-689-9928.
No. Description Qty. No. Description Qty.
1 Air adjusting screw 1 23 Sealing washer 1
2 Air adjusting joint 1 24 Nut compressed spring 1
3 O-ring 2.5 X 2.1 1 25 Trigger level II 1
4 Washer 2 26 Trigger level I 1
5 Air inlet spring 1 27 Trigger 1
6 Air inlet valve 1 28 Snap retainer 2
7 Switch spring 1 29 Canister cover 1
8 Air inlet valve 1 30 Canister 1
9 Switch knob 1 31 Filter 1
10 O-ring 4.9 X 1.5 1 32 Fluid inlet joint 1
11 Switch seat 1 33 Needle 1
12 Sealing washer 2 34 Spring 1
13 Lock screw 1 35 Paint adjusting joint 1
14 Round nut 1 36 Paint adjusting screw 1
15 Air cap washer 1 37 Bolt 1
16 Atomization 1 38 Pattern adjusting screw 1
17 Nut housing 1 39 Pattern adjusting joint 1
18 O-ring 17 X 1.5 1 40 O-ring 2 X1.5 1
19 Fluid nozzle 1 41 Snap retainer 1
20 Fluid nozzle washer 1 42 Pattern adjustment seat 1
21 Screw 1 43 Gun body 1
22 Needle washer 1 44 Air inlet plug 1
