31
30
model no. 054-1232-4 | contact us 1.800.689.9928
TROUBLESHOOTING
Problem Cause of the Problem
Suggested Corrective
Action
Laser line is not
projected
Laser switch is not
turned on or the tool isn’t
plunged in
Make sure the tool is
plugged in and the laser
switch is turned on
Laser line is hard
to see
Working condition is too
bright
Use laser-enhancing glasses
(available separately)
LED worklight does
not light
The tool isn’t plunged in
Make sure the tool is
plugged in
The scrolling control
cannot be turned
The Orbit/Scrolling lever
is not in the “Scrolling”
position
Set the lever in the
“Scrolling” position
If the problem remains unsolved after performing the checks described above,
call the toll-free helpline at 1-800-689-9928.
EXPLODED VIEW
WARNING!
• Turn the ON/OFF switch to the “OFF” position and unplug the
saw from the power source before performing troubleshooting
procedures.
