MasterCraft MAXIMUM 054-1232-4 User Manual

11
10
model no. 054-1232-4 | contact us 1.800.689.9928
PACKAGE CONTENTS
Orbital jigsaw, wood cutting blade, dust extraction port, edge guide and
instruction manual
KEY PARTS DIAGRAM
3 2 16
13
4
10
6 7819 20
11
15
9
12
1
5
18
17
21
14
NO. PART NO. PART
1 Scrolling control knob 12 Vacuum blower knob
2 On/Off trigger switch 13 Tool-less blade clamp
3 Power Lock-on button 14 Variable-speed dial
4 Release button 15 Scrolling/Orbit control lever
5 Hex wrench 16 Top handle
6 Push-on switch 17 Edge guide
7 Blade storage 18 “Live tool indicator” LED light
8 Bevel-angle scale 19 Edge-guide mounting slot
9 Locking knob for edge guide 20 Base plate
10 Blade guide 21 Laser aperture
11 Laser on/off button
KEY PARTS DIAGRAM
WARNING!
• Remove the orbital jigsaw from the package and examine it carefully.
Do not discard the carton or any packaging material until all parts
have been examined.
• If any part of the orbital jigsaw is missing or damaged, do not plug
the tool in or use it until the part has been repaired or replaced.
Failure to heed this warning could result in serious injury.
FPO
KEY PARTS DIAGRAM
