CIRCLE CUTTING GUIDE OPERATION – cont’d
5. Turn the switch ON.
6. When the motor is up to full speed, slowly tip the tool
and circle cutting guide assembly to an upright
position, letting the bit cut into the workpiece (see Fig.
14). Be careful to keep the pivot point located at the
centre of the circle to be cut. Once the tool has
reached the upright position and the bit has cut
through the workpiece, slowly move the tool in a
clockwise direction using slow steady pressure to
make the cut. Continue to cut the circle, keeping the
tool upright and rotating around the circle cutting guide
pivot point.
7. When cut is complete, turn the tool OFF, wait until it
comes to a complete stop and remove it from the
workpiece.
