PARTS LIST
47
MIG 180 INVERTER WELDER 058-9306-4
No. Description Qty. No. Description Qty.
1 Hinge 2
24
Indicator
1
2 Case cover 1
25 Wire speed potentiometer 1
3 Wire retainer 2
26 Voltage potentiometer 1
4 Control transformer 1
27 Potentiometer knob 2
5 Main PC board 1
28
Ground cable and clamp
1
6 Door 1 29 MIG Torch 1
7 Door lock 1 30 American Connector 1
8 Spool holder 1 31 MIG torch receptacle 1
9 Spring 1 32 Wire feeder assembly 1
10 Board 1 33
Welding mode (MIG/Stick)
selector
1
11 Holder 1 34 Quick connector, female 2
12 Spool adaptor 1 35 Trigger lead receptacle 1
13 Spool fixed cover 1 36 Feet 4
14 Washer 1 37 Sheet metal case base 1
15 Butterfly nut 1 38 Loaded PCB 1
16 Vertical centre sheet metal 1 39 Capacitance PCB 1
17 Connection terminal (red) 2 40 Heat sink 1
18 Connection terminal (black) 2 41 Rectifier 1
19
Main transformer
1 42 Fan 1
20 Rectifier heat sink 1 43
Middle board 1
21 Reactor assembly 1
44 Back Panel 1
22 Plastic front panel 1
45 Power cord retainer 1
23
Front panel support
1
46
Power cord
1
