TECHNICAL SPECIFICATIONS
3
MIG 180 INVERTER WELDER 058-9306-4
WELDER SPECIFICATION
SPOOL GUN (OPTIONAL) SPECIFICATION
POWER SUPPLY Single-phase, 230 V, 60 Hz
NO-LOAD VOLTAGE 78 V
OUTPUT CURRENT 30–200 A DC
DUTY CYCLE 30%
WIRE USED
0.023–0.035"
(0.6 – 0.9 mm) MIG wire
0.030–0.035"
(0.8 – 0.9 mm) flux-core wire
WIRE DIAMETER
0.023"
(0.6 mm) , 0.030" (0.8 mm) ,
0.035"
(0.9 mm)
ELECTRODE DIAMETER 1/16" (1.6 mm) , 5/64" (2.0 mm) , 5/32" (4.0 mm),
3/32"
(2.5 mm) , 1/8" (3.2 mm)
DIMENSIONS (L x W x H) 17 7/10 x 9 2/5 x 13 4/5" (450 x 239 x 351 mm)
WEIGHT 48 lb 2 oz (21.8 kg)
CONNECTOR 4-pin quick connect power connection
MOTOR VOLTAGE 24 V DC
WIRE SPEED 590"/min
RATING
200 A w/CO
2
gas
140 A A/Ar gas
