Page 8
align with the corresponding arrow and insert
into the slot until it is secured in place
(Fig. 6a-6d).
.
Fig. 6
a
c d
b
7. Your vacuum comes ready for dry vacuum
cleaning. If the cartridge filter is not installed,
refer to page 18 for installation instructions
(Fig. 7 & 8).
Fig. 7 Fig. 8
8. For wet vacuum cleaning, remove the
cartridge filter, and install the supplied foam
wet filter. See page 20 for the foam wet filter
installation instructions (Fig. 9).
Fig. 9
9. Place the power head back on the collection
tank and secure into place using the latches
(Fig. 10 & 11).
Fig.10 Fig.11
10. Insert the locking end of the hose into the
vacuum port on the collection tank and turn
to lock into place (Fig. 12).
Fig. 12
12. Choose the desired accessory and insert
onto the end of the hose or extension wand
(Fig. 13).
Fig. 13
GENERAL ASSEMBLY INSTRUCTIONS
