MasterForce v - Parts List; Parts Identification (1-20)

MasterForce v
26 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
22
WARNING: When servicing, use only original equipment replacement parts. The use of any
other parts may create a safety hazard or cause damage to the angle grinder.
Any attempt to repair or replace electrical parts on this angle grinder may create a safety hazard
unless repairs are performed by a qualified technician. For more information, call the Toll-free
Helpline, at
1-866-349-8665 Friday from 9am to 5pm Eastern Standard Time.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
2040210006
Outside flange
1
2
6080010001
Grinding wheel
1
3
3140070022
Disc brake "O" ring
1
4
2010140054
Inner flange
1
5
1270030019
125mm Safety wheel guard
1
6
2040040103
Output spindle
1
7
2030170001
Dustproof ring
1
8
4020010003
Screw M4×12
4
9
4040030001
ф4 Spring washer
4
10
2020150076
Gear cover
1
11
4010010081
Bearing 6201 RS
1
12
4100010005
Circlip for Shaft ф32
1
13
2040110041
Driven gear
1
14
4010020003
HK0810 Needle bearing
1
15
4100040006
Circlip for shaft ф7
1
16
4020010153
Screw M3×6
2
17
2030030256
Sealed plate
1
18
4030010106
Screw ST3.9×19
10
19
2020050073
Gear housing
1
20
2050040061
Spindle lock spring
1
!
