13
Installing the Adaptor Plate
Using Table 1/1a (pg.11-12)
and the template provided at
the end of this manual, mark
and punch a 1/4" (6,35mm)
hole in the template as shown.
1
Insert 1/4" (6,35mm) Shaft through
paper template into collet of router.
2
Using the template and router base,
locate and mark the center of router
plate retaining screws.
3
Using the punch, make hole
through the template on all
router plate retaining screws.
4
Take router adapter plate and place
over template, making sure to align
edge correctly.
5
Router adapter plate and template
properly aligned.
6
To Next Page
