Mastervolt AC Master 24/2500

20
ENGLISH
Parallel configuration
DIP switch 4 DIP switch 5 DIP switch 6 DIP switch 7
Master 0 0 0 1
Slave 0 0 1 1
3 phase configuration
DIP switch 4
DIP switch 5
DIP switch 6
DIP switch 7
Master (0°)
0
0
0
1
Slave (-120°) 1 0 0 1
Slave (120°) 1 0 1 1
LCM remote or DIP switch control select
DIP switch 8
LCM remote control ON 0
DIP switch control ON 1
9. Operation
LED indicator
LED color
LED indication
Meaning
What to do?
Green
Solid
Power OK
Normal operation
Green
Slow blinking
Power
Saving Mode
Normal operation
Green
Intermittent blinking
Bypass Normal operation
Orange
Fast blinking
Warning: DC-
input voltage
too high
Check battery voltage and switch off
charger.
Orange
Slow blinking
Warning: DC-
input voltage
too low
Check if DC input voltage is too low
because of voltage drop across the
DC cables due to too long or too
narrow cables. Reduce the length of
the DC cables or use cables with a
larger gauge.
Loose or corroded connections:
Tighten the connections; burnt cables
must be corrected immediately.
Flat battery: Disconnect the load and
