Mastervolt AC Master 24/2500

28
ENGLISH
AC Master 12/3500-230
Product code
28013500
General specifications
Output voltage
230/240 Vac (± 3%) –
50/60 Hz (± 0,1%)
Output waveform
True sine
Nominal battery voltage
12 V
Cont. power at 40 °C, cos phi 1
3500 W
Peak load
4500 W (3 s) ; 6000 W (0,2 s)
Connection
Hard wire / Continental European
(SCHUKO)
Parallel configuration
Up to 15 units
3-Phase configuration
Up to 3x1 (1 unit per phase)
Efficiency
90%
Display/read-out
1 x LED
Dimensions, hxwxd
283 x 128 x 496 mm
Weight
10 kg
Approvals
CE, Safety: EN60950-1, E-mark:
CISPR25, ISO7637-2, EMC: EN
55014-1, EN 55014-2, EN61000-3-2, -
3-3, EN61204-3, EN 61000-6-1, -6-2, -
6-3, -6-4, IEC 61000-4-2, 3, 4, 5, 6, 11
Technical specifications
Technology
High frequency
Battery voltage range
10,0 V – 16,0 V
Low battery voltage, switches off at
10,0 V
Low battery voltage, switches on at
12,5 V
High battery voltage, switches off at
16,0 V
High battery voltage, switches on at
15,0 V
Input current (nominal load)
350 A
No-load power consumption
On mode: < 3,6A @ 12 V
Energy Saving mode: < 1,4 A @ 12 V
Minimal DC fuse (slow blow)
400 A
Minimal cable size
120 mm²
Harmonic distortion typical
< 3 %
Cos phi
All power factors allowed
Temperature range (ambient temp.)
-20 °C to 60 °C, derating > 35 °C
Cooling
Fan
Protection degree
IP21 (if horizontally wall mounted)
Protections
Over temperature, over load, short
circuit, high/low battery voltage, AC
overcurrent (breaker)
AC input transfer system
AC input
20 A (circuit breaker)
Transfer time speed
Inverter to AC input: 8~10 ms
AC input to Inverter: 16~50 ms
Transfer voltage range
230/240 Vac (± 12,5%)
Transfer frequency range
47-57 Hz (50 Hz) / 53-63 Hz (60 Hz)
Options
Remote control
Yes
