24
Value
Meaning
Factory setting
Adjustable. Range
Temp.
compensate
Temperature depended charge voltage compensation
-0,030V/°C/
-0,060V/°C
-1,000/+1,000V/°C
Smart terminal
Smart terminal operation mode
10A Starter
Starter, Starter +
alternator, Follow
main, Follow main +
alternator, 12V
constant voltage, 24V
constant voltage*,
12V 3-step +*
Maximum current
Smart terminal maximum DC input/output current
40/20A
5-40/20A
Bulk
Voltage
Bulk voltage (@ 25°C); see section 3.4
14.40/28.80V
0-15.50/0-31.00V
Minimum time
Minimum time of the Bulk phase since Start bulk timer
120sec
0-240sec
Start time at
Battery voltage trigger point to start the bulk timer
13.25/26.50V
(read only)
Maximum time
Maximum time of the Bulk phase since Start bulk timer
480 min
0-1440min
Absorption
Voltage
Absorption voltage (@ 25°C); see section 3.4
14.25/28.50V
0-15.50/0-31.00V
Maximum time
Maximum absorption timer
240min
0-1440min
Return Amps
Return amps. If the charge current drops below this
level, the charger switches from the Absorption to the
Float stage (% of I
max
)
6%
0-50%
Minimum time
Minimum absorption timer
15min
0-240min
Float
Voltage
Float voltage (@ 25°C); see section 3.4
13.25/26.50V
0-15.50/0-31.00V
Return to bulk
Return to bulk voltage; If the battery voltage stays below
this level for at least the Return to bulk delay time, the
charger will start the Bulk stage
13.25/26.50V
0-15.50/0-31.00V
Return to bulk
Return to bulk delay time, see Return to bulk voltage
30sec
0-240sec
Alarm levels
High alarm on
Upper threshold level to trigger the Battery high alarm
15,25/30.50V
0-16.00/0-32.00V
High alarm off
Lower threshold level to stop the Battery high alarm
14,75/29,50V
0-16.00/0-32.00V
Low alarm off
Upper threshold level to stop the Battery low alarm
11.00/22.00V
0-16.00/0-32.00V
Low alarm on
Lower threshold level to trigger the Battery low alarm
10.00/20.00V
0-16.00/0-32.00V
Alarm delay
Delay time before the alarm is triggered
30sec
5-60sec
Output 1
In use
Select if the output is used
Selected
Selected/Not selected
Name
Name of this output
Output 1
0-16 chars
Shunt device
Selection of the Mastershunt to which output 1 of the
ChargeMaster Plus is connected
No connection
No connection,
MSH + Product Name
Output 2
In use
Select if the output is used
Selected
Selected/Not selected
Name
Name of this output
Output 2
0-16 chars
Smart terminal
In use
Select if the output is used
Selected
Selected/Not selected
Name
Name of this output
Output 3
0-16 chars
*24V models only
