7.2 SPECIFICATIONS 24V MODELS
Model
24/40-3
24/60-3
Article no.
44320400
44320600
GENERAL
Nominal input voltage*:
120/230V
120/230V
Nominal input frequency:
50/60Hz
50/60Hz
Full load consumption
1400VA
2000VA
Max. AC input current (@ 230VAC)
8A
10A
Max. AC input current (@ 120VAC)
16A
20A
Nominal output voltage:
24V
24V
Total charge current*:
40A at 28.8V
60A at 28.8V
Number of battery outlets:
3
3
Max. current Smart terminal:
40A/20A/10A(12V)
60A/20A/10A(12V)
Max. input voltage Smart terminal
32V
32V
Charge characteristic*:
IUoUo, automatic, three step plus
Charge voltage Bulk*:
28.8V
28.8V
Charge voltage Absorption*:
28.5V
28.5V
Charge voltage Float*;
26.5V
26.5V
Max. absorption and max. bulk timer*:
8 hours (start max. bulk timer at 26.5V)
Minimum absorption time*:
15 min.
15 min.
Maximum ripple voltage on DC
240mV pp
240mV pp
Battery type settings*:
User defined/AGM/GEL/Flooded/AGM Spiral/Flooded traction/Flooded calcium/MLi
Dimensions (mm):
383x250x126
383x250x126
Dimensions (inch):
15.0x9.8x5.0
15.0x9.8x5.0
Weight:
<7kg (<16Lbs)
<7kg (<16Lbs)
Recommended battery capacity:
160-400Ah
200-500Ah
Power factor regulations
≥0,98
≥ 0,98
Temperature compensation
Battery temperature sensor and cable included.
Voltage compensation
Yes, by means of automatic compensation or MasterShunt
DC consumption
<10mA
<10mA
Temperature range
–25°C (–13°F) to 80°C (176°F)
Derating of 90% below 0°C (32°F)
Derating 1%/°C (0,5%/°F) from 40°C (104°F) to 60°C (140°F) ;
Derating 8%/°C (4,4%/°F) from 60°C (140°F) to 70°C (158°F) ;
Communication available, 0% output power from 70°C (158°F) to 80°C (176°F)
Cooling
Vario fan and natural cooling to ensure optimized cooling
Sound level
<52dBA / 1m
Protection degree
IP23
IP23
MasterBus connectivity
Yes
Yes
Powering capabilities for MasterBus
Yes, when the charger is switched on, it can power up to three non-powering
devices.
* Adjustable, see chapter 5 for settings
Specifications are subject to change without prior notice.
