November 2004 / MOBILE WHISPER 6/12-6/8/10/12/16 ULTRA / EN 15
INSTALLATION SPECIFICATIONS
3 INSTALLATION SPECIFICATIONS
3.1 TECHNICAL DATA W6/12 W6 ULTRA
Dimensions wxdxh. W 6: 660 x 495 x 550, W 12/6 ULTRA: 810 x 525 x 615
Weight W 6: 178 kg / 12: 210 kg / 6 ULTRA: 225 kg
including soundshield
Max. operation angle 25°
Remote panel 15 m cable, indicating: run, load, overload, failure, hour counter, glow-, start-, stop button.
Battery capacity min. 12V, 85Ah
Fuel consumption 1.5-4 l/hr, load dependent
Fuel lift pump 12 ULTRA electric driven 12 V DC, max. lift 1 m
Cooling radiator cooling
Crank case lube oil capacity, 6: 2.4 l. + 0.5 oil filter, total 2.9 l.;
12/6 ULTRA: 3.6 l. + 0.5 oil filter, total 4,1 l.
Alternator synchronous brushless, maintenance free water cooled
Voltage regulation capacitor (AVR optional)
Output power at W 6: 5.2 kW, 230V 50 Hz
power factor cos phi =1 W 6 ULTRA: 5.7 kW, 230V 50Hz
W 12: 10 kW, 230V 50Hz
Battery charging alternator including regulator (40 Amps)
TECHNICAL DATA W8/10/12/16 ULTRA
Dimensions wxdxh. W 8/10 ULTRA: 900x610x690, 12 ULTRA:1060 x 615 x 690,
W 16 ULTRA: 1150 x 680 x 750
Weight W 8/10/12 ULTRA: 310 kg
W 16 ULTRA: 420 kg
Max. operation angle 25°
Remote panel 10 m cable, indicating: run, load, overload, failure, hour counter, glow-, start-, stop button.
Battery capacity min. W 12 12V, 85 Ah W 16 12V 120Ah
Fuel consumption 1-6 l/hr, load dependent
Fuel lift pump W 8/10/12 ULTRA electric driven 12 V DC, max. lift 1 m
Fuel lift pump W 16 ULTRA mechanical driven; manually priming; lift 1m.
Cooling radiator cooling
Alternator synchronous brushless, maintenance free water cooled
Voltage regulation capacitor + AVR (optional)
Output power at W 8 ULTRA: 1 kW, 230V 50 HZ W 12 ULTRA: 12 kW, 230V 50 Hz
power factor cos phi =1 W 10 ULTRA: 1 kW, 230V 50 HZ W 16 ULTRA: 16 kW, 230V 50Hz
Battery charging alternator including regulator (50 Amps)
