Mastervolt Whisper 12 Installation Manual

November 2004 / MOBILE WHISPER 6/12-6/8/10/12/16 ULTRA / EN 31
ROTOR
STATOR
PE
N
230V 50Hz
L1
230V 50Hz
EARTH AND NEUTRAL CONNECTED
N
PE
L1
EARTH AND NEUTRAL
NOT CONNECTED
MAIN WINDING
BLACK (4)
BLACK (4)
RED (3)
MAIN WINDING
GREEN (2)
RED (3)
EXCITATION
GREEN (1)
WINDING
YELLOW/GREEN
DCC/AC-1
YELLOW/GREEN
BLUE (33) BROWN (33)
BLUE
DCC/ct-1
(11)
RED
CURRENT
TRANSFORMER
(11)
BLACK
CAPACITOR
BROWN
DCC/ct-1
(11)
RED
TRANSFORMER
(11)
BLACK
CURRENT
DCC/AC-1
YELLOW/GREEN
BLUE
YELLOW/GREEN
BROWN
BROWN (33) BLUE (33)
4.5 WIRING DIAGRAM 230V 50HZ
Fig. 36.
DIAGRAMS & DRAWINGS
