DIAGRAMS & DRAWINGS
US / WHISPER 15/20 ULTRA - Three Phase / October 2008 / Copyright © 2008 Mastervolt 29
Wiring colours Whisper 20 Ultra Three Phase
number colour AWG cross section
battery > starter motor red 2 35 mm2
starter motor > DDC 1 red 10 6 mm2
starter motor > LCP 13 red 14 2,5 mm2
battery > ground black 2 35 mm2
ground > LCP ground (GND) 2 black 12 4 mm2
DDC > glow plug 3 brown 12 4 mm2
DDC > starter solenoid 4 yellow 14 2,5 mm2
DDC > LCP 5 grey 16 1,5 mm2
DDC > oil pressure switch 6 purple 17 1 mm2
LCP > oil pressure switch 6 purple/black 17 1 mm2
DDC > water temperature switch 7 blue 17 1 mm2
LCP > water temperature switch 7 blue/black 17 1 mm2
DDC > exhaust temperature switch 8 blue/green 17 1 mm2
LCP > exhaust temperature switch 8 blue/pink 17 1 mm2
DDC > fuel solenoid (hold) 9 green 16 1,5 mm2
DDC > fuel solenoid (pull) 20 pink 14 2,5 mm2
DDC > fuel solenoid (com.) 17 black 14 2,5 mm2
B+ terminal alternator > starter motor 21 red 10 6 mm2
DDC >R terminal alternator 18 white 16 1,5 mm2
DDC > L terminal alternator 19 orange 16 1,5 mm2
DDC > current measuring transformer AC1 66 black 17 1 mm2
DDC > current measuring transformer AC1 66 red 17 1 mm2
DDC > current measuring transformer AC2 77 black 17 1 mm2
DDC > current measuring transformer AC2 77 red 17 1 mm2
DDC > current measuring transformer AC3 88 black 17 1 mm2
DDC > current measuring transformer AC3 88 red 17 1 mm2
DDC > LCP 12 black 16 1,5 mm2
DDC > LCP 14 red 16 1,5 mm2
DDC > LCP 16 red/green 16 1,5 mm2
DDC > generator AC output AC1 33 brown 17 1 mm2
DDC > generator AC output AC1 33 blue 17 1 mm2
DDC > generator AC output AC2 44 brown 17 1 mm2
DDC > generator AC output AC2 44 blue 17 1 mm2
DDC > generator AC output AC3 55 brown 17 1 mm2
DDC > generator AC output AC3 55 blue 17 1 mm2
DDC=Digital Diesel Control Unit
LCP=Local Control Panel
