DIAGRAMS & DRAWINGS
38 Copyright © 2009 Mastervolt / May 2009 / Whisper 7/9.5/15/20 Ultra for mobile applications / US
4.6 WIRING COLOURS WHISPER 20 ULTRA
number colour cross section AWG
battery > starter motor red 35 mm2 2
starter motor > DDC 1 red 6 mm2 10
starter motor > LCP 13 red 2,5 mm2 14
battery > ground black 35 mm2 2
ground > LCP ground (GND) 2 black 4 mm2 12
DDC > glow plugs 3 brown 6 mm2 10
DDC > starter solenoid 4 yellow 2,5 mm2 14
DDC > LCD 5 grey 1,5 mm2 16
DDC > oil pressure switch 6 purple 1 mm2 17
DDC > water temperature switch 7 blue 1 mm2 17
LCP >water temperature switch 7 blue/black 1 mm2 17
DDC > generator temperature switch 8 blue/green 1 mm2 17
LCP > generator temperature switch 8 blue/pink 1 mm2 17
DDC > fuel solenoid (hold) 9 green 1,5 mm2 16
DDC > fuel solenoid (pull) 20 pink 2,5 mm2 14
DDC > fuel solenoid (com.) 17 black 2,5 mm2 14
B+ terminal alternator > starter motor 21 red 6 mm2 10
DDC >R terminal alternator 18 wit 1,5 mm2 16
DDC > L terminal alternator 19 orange 1,5 mm2 16
DDC > current measuring transformer AC-1 11 black 1 mm2 17
DDC > current measuring transformer AC-1 11 red 1 mm2 17
DDC > current measuring transformer AC-2 22 black 1 mm2 17
DDC > current measuring transformer AC-2 22 red 1 mm2 17
DDC > LCP 12 black 1,5 mm2 16
DDC > LCP 14 red 1,5 mm2 16
DDC > LCP 16 red/green 1,5 mm2 16
DDC > generator AC output AC-1 33 brown 1 mm2 17
DDC > generator AC output AC-1 33 blue 1 mm2 17
DDC > generator AC output AC-2 44 brown 1 mm2 17
DDC > generator AC output AC-2 44 blue 1 mm2 17
DDC=Digital Diesel Control Unit LCP=Local Control Panel
