Rev. Descrizione Redatto/Gestito Approvato Cod.Ident. Pagine Data Em.
03 Manuale Istruzioni Ufficio Tecnico Resp.Tecnico C314.M01.EN.03
7/18
03/2009
7
It allows to turn on or to interrupt the working of the whole appliance.
B
Ventilation push-button
It turns on the working of the temperature and humidity control systems and it turns on the inside ventilation.
C
Temperature push-button
It activates the setting to keep the temperature set on the temperature regulator.
D
Climax push-button
It activates the setting to keep the humidity set on the humidity regulator.
E
Inside light push-button
It turns on the inside light (only if it is foreseen on the model of Appliance purchased)
F
Push-button to turn off sound alarms
It turns on or turns off the sound signal (if foreseen: led on = sound signal on)
G
Main supply Signal lamp
It states that the main is feeling the appliance.
H
Cold Signal lamp
It states that the chamber is making the cooling cycle.
I
Hot Signal lamp
It states that the chamber is making the heating cycle.
L
Dry Signal lamp
It states that the room is making the dehumidifying cycle.
M
Moisture Signal lamp.
It states that the room is making the humidifying cycle.
N
Motor contactors Signal lamp
Not foreseen on this model of appliance.
O
Temperature alarm Signal lamp
It states that the chamber has stopped because the highest temperature allowed has been passed.
This happens in case of damages to the inside instruments. Get in touch with the After Sales Service.
P
Water alarm Signal lamp
It goes on when there is no more water feeling (from both the net or the tank).
Q
Temperature regulator
It allows setting the wished temperature during the working of the appliance.
R
Humidity regulator
It allows setting the wished humidity percentage during the working of the appliance.
Chapter 6 USE
DANGER Consult 2.2 DANGEROUS PARTS AND RESIDUAL RISKS before proceeding
6.1 SWITCHING ON THE APPLIANCE
To switch the appliance on act on the switch A (Main Switch – Emergency push-button) turning it on the side indicated
by the arrow.
6.2 SETTING UP THE APPLIANCE
The regulators allow to set the temperature and humidity values that have to be reached and kept inside the chamber
during the test.
