Matrix CS 1200-185 User Manual

18
Handle
Vibration emission value a
h,W
= 1,916 m/s
2
K uncertainty = 1.5 m/s
2
Additional handle
Vibration emission value a
h,W
= 2,669 m/s
2
K uncertainty = 1.5 m/s
2
Important!
The vibration value changes according to the
area of application of the electric tool and
may exceed the specied value in exceptional
circumstances.
5. Before starting the equipment
Before you connect the equipment to the mains
supply make sure that the data on the rating
plate are identical to the mains data.
Always pull the power plug before making
adjustments to the equipment.
5.1 Setting the cutting depth (Figure 2/3)
• Release the handle on the rear of the guard
hood for adjusting the cutting depth (4).
• Place the saw foot (6) at on the surface of the
workpiece you wish to saw. Raise the saw until
the saw blade (12) is at the required cutting
depth (a).
• Refasten the handle for adjusting the cutting
depth (4). Check the handle is securely fastened.
5.2 Miter stop (Figure 4/5)
• The preset standard angle between the saw foot
(6) and saw blade (12) is 90°. You can adjust this
angle to carry out angled cuts.
• Release the locking lever for miter setting (7) on
the front of the saw foot.
• You can now adjust the cutting angle to around
45°. Keep an eye on the cutting angle scale (9) as
you do so.
3. Proper use
The hand-held circular saw is designed for sawing
straight cuts in wood, wood-type materials and
plastics.
The equipment is to be used only for its
prescribed purpose. Any other use is deemed to
be a case of misuse. The user / operator and not
the manufacturer will be liable for any damage or
injuries of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or
industrial applications. Our warranty will be
voided if the machine is used in commercial,
trade or industrial businesses or for equivalent
purposes.
4. Technical data
Mains voltage: 230 V ~ 50 Hz
Power input: 1200 W
Idling speed: 4600 min
-1
Cutting depth at 0°: 65 mm
Cutting depth at 45°: 44 mm
Saw blade: Ø 185 mm
Blade holder: Ø 20 mm
Protection class: II /
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
L
pA
sound pressure level: 90,5 dB(A)
K
pA
uncertainty: 3 dB
LWA sound power level: 101,5 dB(A)
KWAuncertainty: 3 dB
Wear ear-mus.
The impact of noise can cause damage to
hearing.
Total vibration values (vector sum of three
directions) determined in accordance with EN
60745.
