20
correctly connected.
• The moving swing guard hood must not be
xed in the retracted guard hood when the saw
is in use.
Important. Always pull out the power
plug before doing any work on the
circular saw!
6.2 Using the circular saw
• Adjust the cutting depth, cutting angle and
parallel stop (see section 5.1, 5.2 and 5.4)
• Ensure that the ON/OFF switch (2) is not
depressed. Only then should you connect the
mains plug to a suitable socket.
• Do not switch on the circular saw until you have
tted a saw blade.
• Place the saw foot at on the workpiece you
wish to saw. The saw blade must not be in
contact with the workpiece.
• Hold the circular saw rmly with both hands.
• Before you start your sawing work on the
workpiece, you can use the lever (15) to open the
swing guard hood (19) slightly. Starting the
sawing work is then easier.
6.3 Switching ON/OFF (Fig. 9)
To switch on:
Press the locking button (3) and the ON/OFF
switch (2) at the same time
• Allow the saw blade to accelerate until it reaches
full speed. Then slowly move the saw blade along
the cutting line. Only exert gentle pressure on
the saw blade as you do so.
To switch o:
Release the locking button and ON/OFF switch
• If you release the handle the equipment will
shut down automatically which means that it
cannot operate accidentally.
• Ensure that you do not cover or block the
ventilation openings whilst working with the
tool.
• Do not slow down the saw blade after you
switch it o by pressing it sideways.
• Important! Do not put down the machine until
the saw blade has reached a complete standstill.
Important. Carry out a trial cut in a piece
of waste wood
6.4 Changing the saw blade (Fig. 10-13)
Important. Always pull out the power
plug before doing any work on the
circular saw!
Only use saw blades of the same type as the saw
blade supplied with this circular saw. Ask your
dealer for advice.
• Undo the screw to secure the saw blade (17)
using the saw blade key (13).
• Remove the ange (18) and the saw blade (12)
in a downwards direction.
• Clean the ange and insert the new saw blade.
Pay attention to the running direction (see arrow
on the guard hood and saw blade).
• Tighten the screw to secure the saw blade (17),
check it runs true.
• Before you press the On/O switch, make sure
that the saw blade is correctly tted and that
moving parts run smoothly and the clamping
screws are tightened securely.
7. Replacing the power cable
If the power cable for this equipment is damaged,
it must be replaced by the manufacturer or its
aftersales service or similarly trained personnel to
avoid danger.
