Matrix CXV - Page 5

5
ENGLISH
E
F
E
D
A
B
C
B
LEFT
PEDAL
2
Hardware Qty
D Bolt (M6x50L) 1
3
Hardware Qty
E
F
Bolt (M6x55-20L)
Bolt (M8x40L)
2
4
1
Hardware Qty
A
B
C
Bolt (M12x25L)
Flat Washer (M12)
Bolt (M12x70L)
2
4
2
Torque Value
78 Nm / 58 ft-lb.
Torque Value
10 Nm / 7.4 ft-lb
Remove and save for step 4
ASSEMBLY
