Matrix CXV - Page 6

6
ENGLISH
H
H
E
G
H
ASSEMBLY
Loosen top 2 inside screws
Remove bottom 2 inside
screws and save for step 6
Remove outside screws
and save for step 7
H
Torque Value
12 Nm / 8.8 ft-lb.
H
4
Hardware Qty
E
G
H
Bolt (M6x55-20L)
Bolt (M8x40-20L)
Metal plate
2
4
1
From step 3
Route wires using
provided cable ties
7
Hardware Qty
H Screw (M5x12L) 5
6
Hardware Qty
H Screw (M5x12L) 4
From step 5
From step 5
5
Hardware Qty
H Screw (M5x12L) 9
