Matrix ETERNITY NENX User Manual

Matrix ETERNITY NE Quick Start 4
Ports and Connectors
LED
Port
24VDC-2.5A(Max)
CO
SLT
Ethernet
Mobile1 & Mobile2
These are the Single SIM Mobile Ports to connect to the GSM/UMTS
Network.
Descri
p
tion
This is the connector for the Power Adapter.
This is the Analog Trunk Port to connect the Analog Trunk Line.
This is the SLT Port to connect any standard Analog Telephone and Fax
Machine.
This is the Ethernet Port and can be used as LAN or WAN.
• LAN Interface to connect the a Computer/LAN Switch.
• WAN I
nterface to connect to an IP Network. As Ethernet WAN , you can
connect a Router/Modem or a LAN Switch.
/LTE
LED Descri
p
tion Color and Cadence
PWR
This is the Power LED which turns on
when power is supplied.
Continuous ON (Green)
STS
This is the Status LED which blinks to
indicate the status of the System.
1 Sec ON-1 Sec OFF (Green),
on completion of boot-up.
