25
ASSEMBLY
STEP 2 | BOTTOM PAD ASSEMBLY INSTRUCTIONS & NOTES
PART 4: PAD ASSEMBLY
ID DESCRIPTION QUANITY
40 Pad 1
41 M10 X 20L BHC 4
40
41
Install the pad as shown.
Tighten to 27 N-m/20 ft-lbs.
