10
3
4
1
2
P
AR
T 1: USER FRAME ASSEMBL
Y
S
TEP 1
| U
SER FRAME INS
TRUCTIO
NS & NO
TE
S
ID
DESCRIPTION
QUANITY
1
User Frame
1
2
Right Footpad Frame
1
3
M10 X 30L
Hex Bolt
2
4
M10 Saddle W
asher
2
ASSEMBL
Y
T
ip frame as shown to access hardware.
DO NOT FULL
Y
TIGHTEN
View A
Orient the saddle washer
as shown
9
11
Table of Contents
Table of Contents
2
Safety, General Care & Maintenence
3
Getting Started (Product Specifications)
5
Assembly Information
6
Markings
7
Parts List
8
Part 1 Weight Stack & User Frame Assembly
10
Part 2 Cam/Cable Assembly
15
Part 3 Arm Assembly
18
Part 4 Pad Assembly
24
Part 5 Plastics Assembly
26
