Matrix G7-S33 User Manual

8
Parts List
ID
DESCRIPTION
QTY
1 User Frame 1
2 Right Footpad Frame 1
3 M10 X 30L Hex Head Bolt 6
4 M10 Saddle Washer 10
5 Left Footpad Frame 1
6 M10 X 30L Socket Head Cap Screw 8
7 M10 Flat Washer 16
8 Weight Stack 1
9 M10 Nylock Nut 7
10 M10 X 75L Socket Head Cap Screw 4
11 Connecting Tube 1
12 M10 X 110L Socket Head Cap Screw 1
13 Large Pivot Cap 1
14 CAM 1
15 Weight Stack Cable 1
16 M10 X 50L Socket Head Cap Screw 1
17 Pulley 1
18 User Frame Cable (Preassembled to CAM) 1
19 Swingarm 1
20 Small Pivot Cap 3
21 M10 X 105L Socket Head Cap Screw 1
22 M6 Nylock Nut 1
23 M6 Shoulder Bolt 1
24 M10 X 55L Socket Head Cap Screw 4
25 Pivot Block Assembly 1
26 M6 X 12L Socket Head Cap Screw Seat 4
27 M6 Flat Washer 4
28 Tie Rod 2
29 M10 X 15L Socket Head Cap Screw 2
30 Snap Ring 2
31 Left Arm 1
32 Wave (Spring) Washer 2
33 Right Arm 1
