18
P
AR
T 3: ARM ASSEMBL
Y
S
TEP 1
| PIV
O
T BL
OCK ASSEMBL
Y INS
TRUCTIO
NS & NO
TE
S
ID
DESCRIPTION
QUANITY
24
M10 X 55L
SHC
4
25
Pivot
Block Assembly
1
ASSEMBL
Y
25
24
Hand thread M10 bolts and leave loose
***Note: Pivot Block is symmetrical***
Axles must be red Loctited (Loctite 272) and
torqued to: 180 N-m/133 ft-lbs.
17
19
