S
TEP 3
| SWINGARM ASSEMBL
Y INS
TRUCTIO
NS & NO
TE
S
ID
DESCRIPTION
QUANITY
7
M10 Flat W
asher
1
9
M10 Nylock Nut
1
19
Swingarm
1
20
Small Pivot Cap
1
21
M10 X 105L SHC
1
22
M6 Nylock Nut
1
23
M6 Shoulder Bolt
1
T
ighten M10 to 77 N-m/57 ft-lbs.
ASSEMBL
Y
P
AR
T 2: CAM/
CABLE ASSEMBL
Y
Assemble cable into swingarm and tighten M6 to 16 N-m/142 in-lbs.
22
23
9
7
20
19
21
16
18
