MG-A691-05 FRAME ASSEMBLY
NOTE: If your rack is not equipped with spotter stands, proceed to step 2.
1. Place bases and spotter stands where the machine is to be used. Using (16) 3/8-16 x 3 1/4” bolts, (32) 3/8” washers and (16) 3/8 lock nuts, attach the spotter stands to the bases and
torque all bolts to 30 ft-lbs.
2. Place (2) lower base support and (4) bases where the machine is to be used. Using (8) 3/8-16 x 1” bolts and (8) 3/8” washers, attach base support to bases and torque all bolts to 30 ft-lbs.
3. Using (4) 3/8-16 x 3/4” BHCS, attach the diamond plate to the (2) rear supports. Do not tighten bolts.
4. Attach each upright to the base using (16) 3/8-16 x 1” bolts and (16) 3/8” washers. Do not tighten bolts.
STEP 1
STEP 2
STEP 3
STEP 4
