MG-A691-05 FRAME ASSEMBLY
5. Upright support: Using (8) 3/8-16 x 1” bolts, (8) 3/8-16 x 5” bolts, (24) 3/8” washers, and (8) 3/8” nuts, attach the upright support to the bottom of the
upright and the base. Do not tighten bolts.
6. Weight storage bottom: Using (16) 3/8-16 x 1” bolts and (16) 3/8” washers, attach the bottom of the weight storage to the bases. Do not tighten bolts.
7. Chin bar: Using (16) 3/8-16 x 4” bolts, (32) 3/8” washers, and (16) 3/8-16 nuts, attach both chin bars between the tops of the uprights. Do not tighten bolts.
8. Upright cross support: Using (16) 3/8-16 x 5” bolts, (32) 3/8” washers and (16) 3/8” nuts attach, the
upright cross support between the uprights. Do not tighten bolts.
9. Weight storage top: Using (8) 3/8-16 x 4” bolts, (8) 3/8” fender washers, (8) 3/8” washers and (8)
3/8” nuts, attach the top of the weight storage to the upright cross support. Do not tighten bolts.
10. Tighten bolts: Starting with the center diamond plate and working from bottom to top, tighten all
bolts to 30 ft-lbs.
Assembly Complete!
STEP 5
STEP 6
STEP 7
STEP 8
STEP 9
3/8” Fender washer
