MG-A694-05 FRAME ASSEMBLY
NOTE: If your rack is not equipped with spotter stands, proceed to step 2.
1. Place bases and spotter stands where the machine is to be used. Using (8) 3/8-16 x 3 1/4” bolts, (16) 3/8”
washers and (8) 3/8 lock nuts, attach the spotter stands to the bases and torque all bolts to 30 ft-lbs.
2. Place lower base support and bases where the machine is to be used. Using (4) 3/8-16 x 1” bolts and (4)
3/8” washers, attach base support to bases and torque all bolts to 30 ft-lbs.
3. Attach each upright to the base using (16) 3/8-16 x 1” bolts and (16) 3/8” washers. Do not tighten bolts.
4. Weight storage: Using (8) 3/8-16 x 1” bolts and (8) 3/8” washers, attach the bottom of the weight storage
to the bases. Do not tighten bolts.
5. Weight storage top: Using (8) 3/8-16 x 5” bolts, (16) 3/8” washers, and (8) 3/8” nuts, attach the top of the
weight storage to the uprights. Do not tighten bolts.
STEP 1
STEP 2
STEP 3
STEP 4
STEP 5
