MG-A694-05 FRAME ASSEMBLY
6. Upright support: Using (16) 3/8-16 x 5” bolts, (32) 3/8” washers and (16) 3/8” nuts, attach the upright
support between the bottom of the uprights. Do not tighten bolts.
7. Chin bar: Using (8) 3/8-16 x 4” bolts, (16) 3/8” washers and (8) 3/8-16 nuts, attach the chin bar between the
tops of the (2) tall uprights. Do not tighten bolts.
8. Tighten bolts: Starting with the bottom of the uprights and working your way up to the top of the
machine, tighten all bolts to 30 ft-lbs.
Assembly Complete!
STEP 6 STEP 7
