MG-MR691-04 FRAME ASSEMBLY
5. Upright support and Weight Storage Top: Using (24) 3/8-16 x 1” bolts and (24) 3/8” washers, attach the upright support to the top of the uprights and top of
the weight storage. Do not tighten bolts.
6. Upright/Chin bar support: Using (16) 3/8-16 x 1” bolts and (16) 3/8” washers, attach the upright/chin bar supports between the uprights. Do not tighten bolts.
7. Chin bar: Using (8) 3/8-16 x 1” bolts, (8) 3/8” washers, (8) 1/2-13 x 4 1/2” bolts, (16) 7/16” washers and (8) 1/2-13 nuts, attach the chin bar between the top upright
supports. Do not tighten bolts.
8. Diamond Plate: Using (4) 3/8-16 x 3/4” BHCS, attach the diamond plate. Do not tighten bolts.
9. Tighten bolts: Starting with the bottom of the uprights and working up to the top of the machine, tighten all bolts to 30-ft lbs.
Assembly Complete!
STEP 5
STEP 6
STEP 7
STEP 8
