Matrix MW200 - Loading and Test Data; Capacity and Loading Guidelines; Programme Test Specifications

16
Standard loading and test data
Capacity
• Upper and lower baskets: 10 place settings (See Fig. 12).
• The upper basket should be adjusted to high position.
• Cups should be placed onto the dish rack pins.
• Cup racks should be placed above the wire.
Detergent / Rinse aid
• 5 + 25cm
3
, in accordance with EN50242-DIN 44990 IEC436 (international
norms) / Rinse aid dosage adjustment: 5.
Programme test
• Eco 50°C, in accordance with EN50242 (international norms.).
1 2 3 4 5 6 7 8
3 3
3
3
3
3
3
3
3
3
2
2 2 2
2 2 2
2
2 2
6
1 1
1
1 1 1
1
1
1
1
8
5 5
5
5
5
5
5
5 5 5
4 4 4
4
4
4
4 4
4 4
Fig. 12
