Matrix PERFORMANCE CLIMBMILL User Manual

5
ENGLISH
L
6
6
L
6
6
D
E
E
C
F
G
F
6
6
C
H
I
A
B
ASSEMBLY
1
Hardware Qty
A
B
Bolt
Washer
4
4
Torque Value
24 Nm / 17.7 ft-lb
3
Hardware Qty
H
I
Bolt (20mm)
Bolt (10mm)
4
2
Torque Value
H - 24 Nm / 17.7 ft-lb
I - 9.8 Nm / 7.2 ft-lb
2
Hardware Qty
C
D
E
F
G
Bolt (16 mm)
Curved Washer
Bolt (20 mm)
Flat Washer
Bolt (35 mm)
7
4
20
13
2
Torque Value
24 Nm / 17.7 ft-lb

Matrix PERFORMANCE CLIMBMILL Specifications

General

Brand	Matrix
Model	PERFORMANCE CLIMBMILL
Category	Elliptical Trainer
Language	English
