6
ENGLISH
ASSEMBLY
ASSEMBLY COMPLETE
Levelers
4
PERFORMANCE
1. Connect the wires from the
frame to the Base Step.
2. Lift the Control Zone over the
caster wheels. Push down firmly
on both sides until it seats firmly.
3. Slide the Sweat Collector Tray
under the ClimbMill, latching
the handle to the base.
LOCATION OF THE UNIT
Place the unit on a level and stable surface away from direct sunlight. The intense UV light can
cause discoloration on the plastics. Locate your unit in an area with cool temperatures and low
humidity. Please leave a clear zone behind the unit that is at least 24” (610 mm). This zone must
be clear of any obstruction and provide the user a clear exit path from the machine. Do not place
the unit in any area that will block any vent or air openings. The unit should not be located in a
garage, covered patio, near water or outdoors.
HEIGHT REQUIREMENTS
The ClimbMill adds 30 - 38” (76 - 96.5cm) to a users height. For example, a 6’ (183cm) tall user will
be 8’6” - 9’ 2” (259.5 - 279.5cm) off the floor.
BEFORE YOU BEGIN
TRAINING AREA
3.05 M
(10 ft)
1.65 M
(65”)
0.85 M
(33.5”)
FREE AREA
3.05 M
(10 ft)
2.26 M
(89”)
0.85 M
(33.5”)
To Next Page
