2 Matrix SETU VFX Quick Start
SETU VFX880 (VoIP-FXO Gateway)
SETU VFX880 has a WAN Port, a LAN Port, a USB Port, a Reset button, 8 FXO Ports, 9 SIP
Trunks, a Power Socket.
SETU VFX808 (VoIP-FXS Gateway)
SETU VFX808 has a WAN Port, a LAN Port, a USB Port, a Reset button, a Lifeline Port, 8 FXS
Ports, 9 SIP Trunks, a Power Socket.
Power
Adapter
Reset
Button
FXO
Ports
LAN
WAN
USB Port
(Unused)
Power
Adapter
Reset
Button
LifeLine
Port
FXS
Ports
LAN
WAN
USB Port
(Unused)
