Matrix simado gfx11 User Manual

2 Matrix SIMADO GFX11 Quick Start
Ports and Connectors
LEDs
SIMADO GFX11 has 4 LEDs, labeled as FXS, NW, RDY and PWR as shown in the figure below.
SIMADO GFX11E
Port Connector Description
FXS RJ11 To connect a standard Telephon e I nstrument or a PBX.
12VDC-1.25A (Max) DC Jack To connect a Power Adapter.
SIM Card Slot To insert a SIM Card for mobile connectivity.
Antenna SMA (Female) To connect the Antenna for the Mobile Ports.
PWR
(
Power
)
RDY (SIM)
FXS
(
FXS Port
)
NW (Network)
SIM Card Slot
DC Power Jack
FXS Port
Antenna
ON-OFF Button

Matrix simado gfx11 Specifications

General

Brand	Matrix
Model	simado gfx11
Category	Gateway
Language	English
