Matrix Stepper User Manual

3.1 STEPPER
2.2 USING CSAFE
Matrix is the leader in entertainment availability. On the back of the console
are two RJ45 receptacles. They are marked CSAFE and ENTERTAINMENT.
Use the CSAFE port to plug in a CSAFE device using an RJ45 connector.
The connection is as follows:
CPU
UNIT 1
CSAFE
UNIT 2
ENTERTAINMENT
3
2.3 CONSOLE (BACK SIDE) ACCESS LAYOUT
CSA FE
ENT ERTAIN MENT
REPROGRAMMING
CONNECTOR
CSAFE
PORT
ENTERTAINMENT
PORT
Below is a layout to all of the access ports on the back of your Matrix Console.
CHAPTER 3: Serial Number Location
SERIAL#
PLACEMENT
SERIAL # PLACEMENT
CHAPTER 2: Using Manager Preference
06' S5x's OM.indd 7 2006/10/16 10:34:45 AM

Matrix Stepper Specifications

General

Type	Stepper
Brand	Matrix
Category	Fitness Equipment
Display	LCD
Step Range	4-14 inches
Programs	Manual, Rolling Hills, Fat Burn, Target HR, Interval, Constant Watts, Fitness Test
