18
PART 6: UPPER ARM ASSEMBLY
STEP 2 | UPPER ARMS LIMIT ADJUSTMENTS INSTRUCTIONS & NOTES
ASSEMBLY
90 Deg
115 Deg
Outer Limit
90 Deg
Inner Limit
See Detail A on page 19
Note: Outer limit position maintains a clearance of 35 mm between each arm and
the front weight stack shroud
