PART 6: UPPER ARM ASSEMBLY
ASSEMBLY
STEP 2 | UPPER ARMS LIMIT ADJUSTMENTS INSTRUCTIONS & NOTES
Outer Limit Set Screw
Loosen jam nut to make
limit adjustment, and then
retighten
Inner Limit Set Screw
Detail A
