S
TEP 2
| T
OP CAP ASSEMBL
Y INS
TRUCTIO
NS & NO
TE
S
ID
DESCRIPTION
QUANTITY
21
M8 X 25L SHC
4
22
M8 Flat W
asher (2
0 mm diameter)
4
23
T
op Cap
1
22
21
23
ASSEMBL
Y
P
AR
T 6: PL
AS
TICS ASSEMBL
Y
Install the
top cap onto the w
eight stack as shown.
T
orque
to 17 N-m/147 in-lbs.
16
18
